PRODUCT

VLS-200
3D Video Digital Laparoscopy System
Features
  • Depth perception by 3D stereoscopic image
  • Allows more accurate and precise operation
  • Natural color and deep depth perception
  • Short learning curve
  • No dizziness on long operations
VLS-200
Redefining surgical visualization with innovative 3D Technology.

Characteristics

1920×1080P@60Hz High-Definition Image
High quality laparoscope (0°, 30°) , 10mm diameter

Main Unit

MIDAS I
All in One System (CCU + Light Source + Recorder)
User-friendly GUI
Binocuar Disparity Control
Various Video Output HDMI/HD-SDI[L], SDI[R]
Bright LED

Camera & Scope

Crystal clear image (Full hd-60 Frames)
High quality 3D laparoscope (0°, 30°)
Standard 10mm Ø outer diameter
User-friendly key button on camera head
Small and light camera head

Applications

General Surgery
  • General Surgery
  • Colectomy
  • Rectal surgery
  • Common bile resection
  • Gastrectomy
  • Pancreatectomy
  • Bariatric surgery
  • Common bile duct surgery
  • Cholecystectomy
  • Colectomy
  • Splenectomy
  • Gastric bypass
  • Hepatectomy
  • Adrenalectomy
  • Small bowel resection
Cardiothoracic Surgery
  • Lung cancer
  • Pulmonary emphysema
  • Esophagus cancer
  • Esophageal stenosis
  • Chest wall tumor
  • Cardiac surgery
Obstetrics and gynecology
  • Hysterectomy
  • Ovarian cystectomy
  • Myomectomy
  • Hysterectomy
  • Salpingo-Oophorectomy
  • Pelvic lymph node dissection(PLND)
Urology
  • Nephrectomy (Total or partial)
  • Renal cystectomy
  • Pelvic reconstruction
  • Prostate tumor

VLS-200 Accessories (Option)

3D Console Monitor
Optimizing Operation Room
  • The world’s first Console 3D monitor
  • No 3D glasses required, and it keeps optimal distance between eye and console monitor.
  • No binocular disparity control required
  • Distortion free 3D image
  • Full HD resolution for each left and right eyes
  • Able to replace robot-assisted surgery & is safer without moving heavy arm
Kim's console
  • Patented Console 3D monitor, no 3D glasses required
  • Safer than Robot-assisted operation without manipulating heavy arm
  • Proper ergonomic maneuverability
  • Combining surgical comfort with practicality
  • Headrest and functional chair
  • Armrest fixation
Combining Surgical Comfort & Practicality
Kim's Chair offers customizable seat configurations with fully adjustable
backrest and armrests to provide optimal support to meet the surgeon’s
specific positioning preferences.

It’s superior pedal access and a stable, yet mobile, design helps to facilitate
clinical performance.
Human Touch 3D Laparoscopy
Surgery advantages
  • 3D Laparoscopy depth perception recognition (Complementing 2D shortcomings)
  • Haptics from surgeon's direct surgery(complementing robot-assisted surgery shortcomings)
  • Precise and safe
  • Minimization of medical accidents

Product Specifications

Main Unit (MIDAS I)
Image System User Interface TFT touch LCD Food Switch
Resolution 1920x1080/ 60p
Image Adjustment Color, Sharpness, Gamma, Exposure White balance(Manual, Push Set, Auto)
Storage device USB 2.0 Format method: FAT 32 Format
Still image Capture 1920x1080 jpg
Video Record 1920x1080/30 fps, H.264/MPEG-4 10AVC
Video outputs Digital interface HDMI(GUI), HDMI(B), HDMI(A)
HD-SDI (Left), HD-SDI (Right) 1980 X 1080/ 60p
Electrical Specification Input Electrical Ratings 100-240 VAC 50/60 Hz
Light source Light source 60W
More than White LED Lamp, 10x104 Lux (Manufacturer measurement method)
Light Distribution Degree 65˚± 9˚
Light source intensity adjustment Levels 1 to 10 (where, Level 0=OFF)
Cooling Method Air forced fan cooling system
Color temperature 5,200° K ± 5% (Manufacturer measurement method)
Weight Approx. 5.3Kg
Dimensions 310mm (W) x 200mm (H) x 330mm (D)
