VOMS-102D
Innovative 3D video surgical microscope for dentists
Features
- Exceptionally clear 3D Full HD image quality
- New generation head-up posture observation
- Easily controllable camera arm in all directions
- True depth perception and wide field of view
- Distortion free images
Characteristics
- A New Trend In Global Surgery HUD (Head up display) 3D Video Surgical Microscope
-
In the past, Loupe or surgical microscopy was used.
Currently, 3D surgery using high-resolution 3D video microscope is being developed to recognize the depth of the lesion through the monitor and
to further refine and precise surgery.
Distortion free
- Sometech`s patented lens technology minimizes chromatic aberration.
Unsurpassed depth of field
- Sometech’s patented image processing technology provides crystal clear images for the immediate and the surrounding area.
Head Up System
- Relief from neck and lumbar pain, eye strain and headache.
Touch screen GUI and recorder
- VOMS-101D has a built in GUI
Easy and precise movement
-
Ergonomic design allows easy and precise movement.
Surgeons can easily place the camera to focus on surgical area.
2.0X optical zooming by turret
- Adjustable optical zooming up to 2 times by simple twist of turret
2.0x Digital zooming (Footswitch)
-
It has optical and digital zooming system, optical zooming up to
2 times and digital zoom 2 times. Easy to control with the main
unit(GUI) and foot switch during surgery.
Applications
Product Specifications
| Main unit | Dimension | 180mm(W)x160mm(D)x80mm(H) | |
|---|---|---|---|
| CCU | Power | 100-240VAC/50-60Hz | |
| 3D Muxing format | Side by side | ||
| Binocular digital zoom control | 1.0x ~ 2.0x (Step 0.1x) | ||
| Light source | LED | White LED with UV cut filter | |
| Color temperature | 5000°K | ||
| Intensity | 0(off)~10(max), brighter than xenon 300W light source | ||
| LifeTime | 60,000 hours | ||
| 3D Camera | Resolution | Full-HD(1920x1080) 16:9 Ratio, HDMI connector type | |
| Digital zoom | 1.0x ~ 2.0x | ||
| Lens |  |
||
|
3D Monitor (option) |
23" 3D Monitor(standard) | ||
| Resolution | Full-HD(1920x1080) | ||
